Tesla reference
Model Y (2020–2025)
The 5 trims of the Tesla Model Y (2020–2025): battery, rated range and dimensions.
Trims
| Trim | Years | Drive | Markets | Battery | Capacity (gross) | WLTP | EPA |
|---|---|---|---|---|---|---|---|
| Long Range Dual Motor | 2020–2025 | All-wheel drive | United States, Canada, Europe, United Kingdom, China, Asia-Pacific | NCA (Panasonic, Fremont, Austin) United States, CanadaNMC (LG, Shanghai, Berlin) Europe, United Kingdom, China, Asia-Pacific | 75–82.1 kWh usable 72–75 kWh | 507–542 km | 308–330 mi |
| Performance Dual Motor | 2020–2025 | All-wheel drive | United States, Canada, Europe, United Kingdom, China, Asia-Pacific | NCA (Panasonic, Fremont, Austin) United States, CanadaNMC (LG, Shanghai, Berlin) Europe, United Kingdom, China, Asia-Pacific | 78.1–82.1 kWh usable 75–79 kWh | 514 km | 277–315 mi |
| Standard Range | 2021–2025 | Rear-Wheel Drive | United States, Europe, United Kingdom, China, Asia-Pacific | NCA (Panasonic, Fremont, Austin) United StatesLFP (CATL, Shanghai, Berlin) Europe, United Kingdom, China, Asia-PacificLFP (BYD, Berlin) Europe | 60 kWh usable 57 kWh | 430–455 km | 244–260 mi |
| Dual Motor (Austin 4680, Standard Range) | 2022–2023 | All-wheel drive | United States | NMC (Tesla, Austin) United States | – usable 67.1–67.5 kWh | – | 279 mi |
| Long Range Rear-Wheel Drive | 2024–2025 | Rear-Wheel Drive | United States, Canada, Europe, United Kingdom | NCA (Panasonic, Fremont, Austin) United States, CanadaNMC (LG, Berlin) Europe, United Kingdom | 78.1 kWh usable 75 kWh | 600 km | 320–337 mi |
Rated range, depending on wheels and model year. WLTP in Europe, EPA in the United States.
Dimensions
- Length
- 4,751 mm
- Width (without mirrors)
- 1,921 mm
- Height
- 1,624 mm
- Wheelbase
- 2,890 mm
- Doors
- 5
From the Tesla owner's manual. Read the manual
Frequently asked questions
Which battery does the Model Y (2020–2025) use?
Long Range Dual Motor: NCA (Panasonic, Fremont, Austin), markets: United States, Canada; NMC (LG, Shanghai, Berlin), markets: Europe, United Kingdom, China, Asia-Pacific. Performance Dual Motor: NCA (Panasonic, Fremont, Austin), markets: United States, Canada; NMC (LG, Shanghai, Berlin), markets: Europe, United Kingdom, China, Asia-Pacific. Standard Range: NCA (Panasonic, Fremont, Austin), markets: United States; LFP (CATL, Shanghai, Berlin), markets: Europe, United Kingdom, China, Asia-Pacific; LFP (BYD, Berlin), markets: Europe. Dual Motor (Austin 4680, Standard Range): NMC (Tesla, Austin), markets: United States. Long Range Rear-Wheel Drive: NCA (Panasonic, Fremont, Austin), markets: United States, Canada; NMC (LG, Berlin), markets: Europe, United Kingdom.
What is the range of the Model Y (2020–2025)?
Long Range Dual Motor: 507–542 km WLTP, 308–330 mi EPA. Performance Dual Motor: 514 km WLTP, 277–315 mi EPA. Standard Range: 430–455 km WLTP, 244–260 mi EPA. Dual Motor (Austin 4680, Standard Range): 279 mi EPA. Long Range Rear-Wheel Drive: 600 km WLTP, 320–337 mi EPA.
What is the battery capacity of the Model Y (2020–2025)?
Long Range Dual Motor: gross 75–82.1 kWh, usable 72–75 kWh. Performance Dual Motor: gross 78.1–82.1 kWh, usable 75–79 kWh. Standard Range: gross 60 kWh, usable 57 kWh. Dual Motor (Austin 4680, Standard Range): usable 67.1–67.5 kWh. Long Range Rear-Wheel Drive: gross 78.1 kWh, usable 75 kWh.
What are the dimensions of the Model Y (2020–2025)?
It is 4,751 mm long and 1,921 mm wide without mirrors, with a 2,890 mm wheelbase, according to the owner's manual.
What sets the Model Y (2020–2025) apart from the Model Y Juniper (2025–)?
The Model Y (2020–2025) is 4,751 mm long versus 4,794 mm for the Model Y Juniper (2025–), with the same 2,890 mm wheelbase. The trims, batteries and range of each are detailed on their spec sheet.
