Tesla reference
Model 3 (2017–2023)
The 7 trims of the Tesla Model 3 (2017–2023): battery, rated range and dimensions.
Trims
| Trim | Years | Drive | Markets | Battery | Capacity (gross) | WLTP | EPA |
|---|---|---|---|---|---|---|---|
| Long Range | 2017–2023 | Rear-Wheel Drive | United States, Canada, Europe, United Kingdom, Netherlands | NCA (Panasonic, Fremont) United States, Canada, EuropeNMC (LG, Shanghai) United Kingdom, Netherlands | 78.1–78.8 kWh usable 73.5–75 kWh | 600–638 km | 310–330 mi |
| Long Range Dual Motor | 2018–2023 | All-wheel drive | United States, Canada, Europe, United Kingdom, China, Asia-Pacific | NCA (Panasonic, Fremont) United States, Canada, Europe, United KingdomNMC (LG, Shanghai) Europe, United Kingdom, China, Asia-Pacific | 75–82 kWh usable 72–76 kWh | 560–614 km | 310–358 mi |
| Mid Range | 2018–2019 | Rear-Wheel Drive | United States, Canada | NCA (Panasonic, Fremont) United States, Canada | 62 kWh | – | 260–264 mi |
| Performance Dual Motor | 2018–2023 | All-wheel drive | United States, Canada, Europe, United Kingdom, China, Asia-Pacific | NCA (Panasonic, Fremont) United States, Canada, Europe, United KingdomNMC (LG, Shanghai) Europe, United Kingdom, China, Asia-Pacific | 78.1–82 kWh usable 73.5–76 kWh | 530–567 km | 299–315 mi |
| Standard Range | 2019–2020 | Rear-Wheel Drive | United States, Canada | NCA (Panasonic, Fremont) United States, Canada | 50 kWh | – | 220 mi |
| Standard Range Plus | 2019–2021 | Rear-Wheel Drive | United States, Canada, Europe, United Kingdom, China, Asia-Pacific | NCA (Panasonic, Fremont) United States, Canada, Europe, United KingdomNMC (LG, Shanghai) ChinaLFP (CATL, Shanghai) Europe, United Kingdom, China, Asia-Pacific | 53.1–55 kWh usable 49–52.5 kWh | 409–448 km | 240–263 mi |
| Rear-Wheel Drive | 2021–2023 | Rear-Wheel Drive | United States, Canada, Europe, United Kingdom, China, Asia-Pacific | LFP (CATL, Shanghai) Europe, United Kingdom, China, Asia-PacificLFP (CATL, Fremont) United States, Canada | 60 kWh usable 57 kWh | 491 km | 272 mi |
Rated range, depending on wheels and model year. WLTP in Europe, EPA in the United States.
Dimensions
- Length
- 4,695 mm
- Width (without mirrors)
- 1,850 mm
- Height
- 1,445 mm
- Wheelbase
- 2,875 mm
- Doors
- 4
From the Tesla owner's manual. Read the manual
Frequently asked questions
Which battery does the Model 3 (2017–2023) use?
Long Range: NCA (Panasonic, Fremont), markets: United States, Canada, Europe; NMC (LG, Shanghai), markets: United Kingdom, Netherlands. Long Range Dual Motor: NCA (Panasonic, Fremont), markets: United States, Canada, Europe, United Kingdom; NMC (LG, Shanghai), markets: Europe, United Kingdom, China, Asia-Pacific. Mid Range: NCA (Panasonic, Fremont), markets: United States, Canada. Performance Dual Motor: NCA (Panasonic, Fremont), markets: United States, Canada, Europe, United Kingdom; NMC (LG, Shanghai), markets: Europe, United Kingdom, China, Asia-Pacific. Standard Range: NCA (Panasonic, Fremont), markets: United States, Canada. Standard Range Plus: NCA (Panasonic, Fremont), markets: United States, Canada, Europe, United Kingdom; NMC (LG, Shanghai), markets: China; LFP (CATL, Shanghai), markets: Europe, United Kingdom, China, Asia-Pacific. Rear-Wheel Drive: LFP (CATL, Shanghai), markets: Europe, United Kingdom, China, Asia-Pacific; LFP (CATL, Fremont), markets: United States, Canada.
What is the range of the Model 3 (2017–2023)?
Long Range: 600–638 km WLTP, 310–330 mi EPA. Long Range Dual Motor: 560–614 km WLTP, 310–358 mi EPA. Mid Range: 260–264 mi EPA. Performance Dual Motor: 530–567 km WLTP, 299–315 mi EPA. Standard Range: 220 mi EPA. Standard Range Plus: 409–448 km WLTP, 240–263 mi EPA. Rear-Wheel Drive: 491 km WLTP, 272 mi EPA.
What is the battery capacity of the Model 3 (2017–2023)?
Long Range: gross 78.1–78.8 kWh, usable 73.5–75 kWh. Long Range Dual Motor: gross 75–82 kWh, usable 72–76 kWh. Mid Range: gross 62 kWh. Performance Dual Motor: gross 78.1–82 kWh, usable 73.5–76 kWh. Standard Range: gross 50 kWh. Standard Range Plus: gross 53.1–55 kWh, usable 49–52.5 kWh. Rear-Wheel Drive: gross 60 kWh, usable 57 kWh.
What are the dimensions of the Model 3 (2017–2023)?
It is 4,695 mm long and 1,850 mm wide without mirrors, with a 2,875 mm wheelbase, according to the owner's manual.
What sets the Model 3 (2017–2023) apart from the Model 3 Highland (2024–)?
The Model 3 (2017–2023) is 4,695 mm long versus 4,720 mm for the Model 3 Highland (2024–), with the same 2,875 mm wheelbase. The trims, batteries and range of each are detailed on their spec sheet.
